powder

gold powder

Gold powder is a powder material composed of high-purity gold particles, with particle size typically controlled in the micrometer to nanometer range. Among them, nano gold powder has a particle size of less than 100 nanometers and has extremely high specific surface area and surface energy. This unique microstructure endows gold powder with excellent conductivity, thermal conductivity, and chemical inertness, making it of significant application value in fields such as electronic manufacturing, catalysis, and biomedical research.

In principle, the conductivity of gold powder originates from the inherent high conductivity of metallic gold, where electrons can freely transfer between particles to form a conductive path. The surface activity of nanoscale gold powder enables sintering and interconnection between particles at lower temperatures, forming a continuous and dense conductive network. The chemical inertness of gold enables gold powder to maintain stable physical and chemical properties in high temperature, high humidity, and corrosive environments, without oxidation or sulfurization.

The core advantages of this product are: excellent electrical and thermal conductivity, and excellent chemical stability; The particle size and morphology can be customized according to application requirements; Suitable for fields such as high-end electronic pastes, catalysis, and biosensing that have strict requirements for material purity and reliability.

Hotline

+86-13826586185

Highly dispersed ultrafine gold powder is a metal powder with extremely high surface area and excellent physical and chemical properties. Due to its small particle size, typically between 1 and 100 nanometers, it has a large specific surface area, which gives it many unique properties and a wide range of applications.

Product Features

High reactivity and catalytic activity: Due to its large specific surface area, highly dispersed ultrafine gold powder has higher activity in chemical reactions and can be used as an efficient catalyst in fields such as chemical synthesis, environmental protection, and energy conversion.
Excellent electrical and thermal conductivity: Ultra fine gold powder has excellent electrical and thermal conductivity due to its fine particle size and high purity, which makes it important for applications in the electronics industry, such as producing high-performance electronic components, heat dissipation materials, etc.
High chemical and thermal stability: Even in high temperature and strong acid-base environments, this gold powder can maintain stable chemical and thermal stability, making it suitable for use under harsh conditions.

Product Model: Highly Dispersed Ultra fine Gold Powder YB-W100
Product Introduction: Micro or sub micron spherical gold powder with uniform particle size, high sphericity, excellent dispersibility, and high tap density, suitable for high-performance gold powder conductive paste, and can be used as thick film conductor material for IC manufacturing, flat displays, printed circuit boards, and solar cells.

Application recommendation: Mainly used in microelectronic materials as the main raw material for gold conductor paste

Technical Indicators:

Loose density: 5.0~7.0 g/cm3

Compaction density: 6.0~8.0 g/cm3

Average particle size: ≤ 0.70 μ m

Specific surface area: 0.5~2.0 m2/g

Purity: ≥ 99.95% Au (spectral analysis)
