Beryllium copper spring strips that are not affected by nuclear explosions/ultraviolet radiation/ozone, have good pressure resistance, and have flexible and diverse installation methods

Purpose:

      BeCu FingerstockIt is a finger shaped spring made of special alloy beryllium copper, which can be used in a wide range of electronic devices with EMI/RFI or ESD problems. It solves other problems as well

The pad cannot withstand forces in the shear direction, and has low bonding pressure, small deformation range, excellent shielding performance in low and high frequency bands, as well as high thermal conductivity

Light weight, unaffected by nuclear explosions/ultraviolet radiation/ozone, good pressure resistance, and flexible and diverse installation methods.

Application:

Communication, computer, military navigation system, various shielding rooms/cabin doors/chassis doors/cover plates/printed board inserts/integrated circuit shielding, etc.

Installation method of beryllium copper spring

Slot installation beryllium copper spring

The slot installation beryllium copper spring is suitable for various slot installation scenarios, and this product can be used for grounding and EMI shielding. Has the following characteristics:

Low cost of slot processing

No need for glue or fasteners, simple installation

● Allow bidirectional sliding compression, with a wide range of applications

Suitable for grounding and shielding design of front panel, drawer unit, chassis cover, PCB plug-in board, etc

Rivet installation beryllium copper spring

Rivet installation can be done using a plastic expansion nail installation method (with a mounting hole diameter of 3.2mm), which is more secure than backing glue and suitable for use under high temperature conditions. Make holes on the contact surface during use,

Press the rivets on the spring into the holes to secure the spring.
