roll to rollVacuum continuous coating
Electroplating flexible materials: PET, PEN PEI, PC, PI film, copper foil, aluminum foil, cloth, paper, etc
Coating materials: nickel, chromium, aluminum, titanium, copper, tin, indium, indium tin alloy.
Product Description:
Single sided conductive PET film, using advanced optical PET substrate, depositing a high-purity oxygen free copper conductive layer on the surface by vacuum magnetron sputtering; The PET film material is widely used in electronic products for heat dissipation, electrode circuits, and electromagnetic shielding, as it possesses the conductive and thermal properties of a metallic material surface.
Product specifications and physical properties:
| project |
unit |
test method |
Specification value |
Actual measurement value |
||
| nature |
number |
Substrate type |
PET |
|||
| Specification characteristics |
1 |
Product width |
mm |
1200±5 |
1200 |
|
| 2 |
Product thickness |
um |
100±10 |
102 |
||
| 3 |
Cu surface resistance |
Ohm/sq |
ASTM D991 |
≤0.5 |
0.2 |
|
| 4 |
Uniformity of surface resistance value |
﹪ |
ASTM D991 |
TD:≤1.0 MD:≤1.0 |
1.0 |
|
| 5 |
Plating Adhesion |
ASTM D3359 |
≥5B |
5B |
||
| 6 |
Color of conductive layer |
Pure copper color |
||||
| 7 |
heat resistance |
℃ |
120 |
|||
Kind reminder: This product can be divided into single-sided copper plating and double-sided copper plating, which can be customized according to customer needs.
There are multiple thicknesses to choose from, namely: 0.012; 0.018mm； 0.025mm； 0.03mm； 0.05mm； 0.06mm； 0.075mm； 0.08mm； 0.1mm； 0.125mm； 0.188mm, etc.
Length: 300 meters; Width: customizable between 3mm and 1000mm.
